These all-dielectric single loose tube cables are simply but robustly constructed of colour coded 250 micron coated fibres contained in a central tube.
The single tube is surrounded by E-glass or Aramid yarn strength members which also provide rodent resistance.
This is enclosed in a black LSZH outer jacket, compliant with IEC fire performance requirements.
Fibre counts of 4 – 48 fibres are available in all four standard specifications – OM1, OM2, OM3, OM4 and OS1.
E-glass or Aramid yarn strength members provide tensile strength and rodent resistance.
Colour coded fibres for easy identification
Rip cord for easy jacket removal LSZH jacket for internal / external use Black UV resistant jacket as standard
1500N pulling tension.
Compact design for limited conduit space
Internal or externally in ducts
Campus links without the need for transition cable splicing
On site fibre splicing and direct termination
Detailed specification available on request.
Multicore Loose Tube Fibre Cable
